50W COB LED Flood Light Outdoor , IP65 Floodlight 120 Degree Beam Angle
FEATURES :
1. EPISTAR LED Chips, 110LM/W
2. CE, ROHS, EMC, LVD, ISO9001:2008 Certificates,
3. 120°Beaming Angle
4. Die-Casting Aluminum Body, Tempered glass, Stainless Steel Screws
5. High energy efficiency, low power consumption
6. No UV or IR radiation
7. Equivalent to 100W CFL Lams OR 150W GLS Lamps
PARAMETERS:
| Optical Parameters | LED Power: | 1x50W | System Consumption | 50 W |
| LED Chips | EPISTAR | LED Initial Flux | 5000 lm |
| THD | <20% | LED Maintain Flux (After the lens & thermal stabilization) | 4000 lm |
| Colour Rendering Index (CRI) | Ra > 72 | Illumination Pure White 6500K | Mount Height=2M: 62.15 lux Mount Height=3M: 27.62 lux Mount Height=5M: 9.94 lux Mount Height=6M: 6.91 lux |
| Light Distribution Curve | Rectangular Facular | Illuminance Uniformity | >80% |
| Colour Temperature | 4000K-4500K | Beam Angle | 120° |
| Electrical Parameters | Input Voltage | 90-240VDC | IP Rating | IP 65 |
| Power Factor | >0.95 | output voltage | 29-36VDC |
| Frequency Range | 50-60HZ | Lamp Efficiency | >0.80 |
| Power Efficiency | >90% | Non Dimmable | (Not dimming)
Dimming can be done according to the requirements |
| Fitting Parameters | Colours | Black or Grey (Subject to availability) | Packing | 6 PCS /51*48.5*31CM /17KGS/CTN |
| Materials | Aluminium Body Tempered glass Stainless Steel Screws | Working Environment | Temp: -20℃~45℃ Humidity: 10% ~90% |
| Working Life-span | 50,000 hours | Storage Environment | Temp: -20℃ ~50℃ |
Applications:
1. Can be mounted vertically or horizontally, adjustable stand lets you point the light at different angles.
2. Perfect for outdoor project lighting of Building exterior wall, parking lot, stadium, bridge, gardens, square and many other fields.
ATTENTIONS:
1. The light’s waterproof grade is IP65, able to withstand rains, but it can’t work under water.
2. The light’s operating at working temperature between -20℃ and 45℃.
3. Make sure the products are out of reach from children,
4. Please don’t install in flammable ,explosive or corrosive circumstances,
5. Cut off power supply before and in installation process. If the product is damaged due to mal-operation, it will invalid the warranty.
